YCC Curved Rail Side Dumping Car is mainly used for metallurgy, mining, coal mines, railways, highway ramps, underwater culverts, underground mine flats and military culverts, etc., such as simple excavation and high-efficiency transport equipment.
YCC Curved Rail Side Dumping Car is driven by tractors and winches. It can be combined with rock drilling, vertical claw rock loading machine and ore sliding gate discharge system. The ore block is not more than 500 mm, depending on the load of the mine car. The volume is charged to the special track unloading mechanism (loading speed not exceeding 1m/second) after the loading. When the car is turned to the horizontal to the maximum discharge angle, the door is also opened to the maximum procedure. At this time, the mine car unloading is completed. Upon returning, the mine car is automatically closed by the curved door.
MAIN PARAMETER OF|
Parameters |
Curved Rail Side Dumping Car |
||||||
|
1.2M3
|
1.6M3
|
2.5M3
|
4M3
|
6M3
|
8M3
|
||
|
Volume（m3） |
1.2 |
1.6 |
2.5 |
4 |
6 |
8 |
|
|
Load（t） |
1.6 |
4 |
6.25 |
10 |
15 |
15 |
|
|
Track spacing（mm） |
600 |
762 |
762 900 |
762 900 |
762 900 |
762 900 |
|
|
Wheelbase（mm） |
620 |
800 |
1200 |
2000 |
2000 |
2600 |
|
|
Wheel diameter （mm） |
300 |
350 |
400 |
350 |
350 |
350 |
|
|
Coupler form |
Latch chain |
Latch chain |
Latch chain |
Latch chain |
Latch chain |
Latch chain type automatic hook |
|
|
High traction（mm） |
335 |
320 |
320 |
430 |
500 |
500 |
|
|
TractionSpeed（kg/h） |
12 |
12 |
12 |
8 |
8 |
8 |
|
|
Unloading angle （°） |
|
45° |
45° |
42° |
42° |
42° |
|
|
Dimensions |
long（mm） |
2150 |
2500 |
3650 |
3650 |
5000 |
6350 |
|
width（mm） |
1450 |
1200 |
1250 |
1500 |
1800 |
1500 |
|
|
high（mm） |
1270 |
1300 |
1300 |
1586 |
1675 |
1634 |
|
|
weight |
1000 |
1363 |
2205 |
2980 |
3173 |
4750 |
|
|
Turn radius（m） |
8 |
10 |
12 |
15 |
15 |
18 |
|
